Qoltec Smart Monolith charger for LiFePO4 AGM GEL SLA batteries | 20A | 24V

Stable and Safe Energy Source for All LiFePO₄, AGM, GEL, and SLA Batteries
Precise Charging with 7 Configurable Modes to Match Your Battery Type

The Monolith Charger is expertly engineered to deliver stable and safe power to a wide variety of batteries, including AGM, GEL, calcium, SLA, and LiFePO₄. It helps maintain optimal battery health and extends service life with its intelligent charging process.

Discover the Unique Power of Smart Charging

Integrated 3-Stage Charging Process for Maximum Efficiency

The Monolith smart charger uses a 3-stage charging method that dynamically adjusts voltage and current based on the battery's state of charge. This process consists of:

• BULK Phase: Detects the battery condition and charges it up to 80% with constant maximum current and high voltage.

• BOOST Phase: Absorption charging – voltage is held between 28.4VDC and 30VDC while the current is gradually reduced.

• FLOAT Phase: Maintains the battery at 95–100% charge with a lower constant voltage between 26.6VDC and 27.6VDC. Charging current drops to 0A once fully charged.

A built-in LED clearly indicates the current charging phase.

Optimal Performance & Cost Savings

Reliable Maintenance at Every Stage

Benefits of intelligent 3-stage charging:

• Fully and evenly charges the battery to improve performance and lifespan

• Prevents overheating, overcharging, and damage

• Reduces energy loss and minimizes electricity costs

Trust Monolith – Enjoy Uninterrupted Power

Smart Features Packed in a Durable Design

• 7 configurable charging profiles via DIP switch for SLA, GEL, AGM, calcium, LiFePO₄ batteries, or constant voltage mode

• Durable aluminum housing for corrosion resistance and thermal conductivity

• Active cooling fan for temperature regulation during heavy use

• Short-circuit, overcharge, reverse polarity, and overheating protection

• Auto shutdown at end of charge; enters sleep mode when complete

• LED status indicators, included wiring, and two fuses for safety

Designed with Safety First

Comprehensive Protection Features

The charger is isolated at both input and output for maximum safety and includes:

• UVP (Under Voltage Protection)

• SCP (Short Circuit Protection)

• OVP (Over Voltage Protection)

• OCP (Over Current Protection)

• OTP (Over Temperature Protection)

Technical Specifications

• Manufacturer: Qoltec

• Charging Type: 3-stage (Bulk / Boost / Float)

• Input Voltage: 180 – 260V

• Output Voltage: 24V

• Max Output Current: 20A

• Efficiency: 88%

• Cooling System: 1x fan with thermal control

• Load Regulation: 1.5% from no-load to full-load

• Connectors: Red + black crocodile clamps with brass terminals

• Cable Length: ~0.90 m

• Supported Battery Types: LiFePO₄, AGM, GEL, SLA, Calcium, EFB

• Operating Temperature: 0°C ~ +40°C

• Dimensions: 150 x 305 x 75 mm

• Protection:

  • Short-circuit

  • Overheating

  • Overcurrent

  • Low voltage

  • Overvoltage

  • Reverse polarity

Included in the Box

• 1 × Battery Charger

• 1 × Power Cable

• 1 × Starter Cable Set

• 2 × Fuses

• 1 × User Manual

Note:

• Always match cables to the correct terminals

• Disconnect all devices before removing the battery

• Use with rechargeable batteries only

• Do not attempt to charge frozen or damaged batteries

Certification: CE
Net Weight: 1.96 kg
Gross Weight: 2.50 kg
Packaging Size: 375 × 200 × 140 mm
