Victron Energy BMV-712 Smart Battery Monitor - BMS

The BMV-712 is a high accuracy battery monitoring device. The basic purpose of the battery monitor is to calculate the ampere-hours of consumption and the battery charge status. The ampere-hours consumed are calculated by integrating the current flowing into and out of the battery. For more information on the complete BMV product range and its accessories, please see the following blog. Wide input voltage range: 6.5 - 70V

The BMV-712 unit includes a round header, a square insight glass enclosure, a screw ring for mounting, a 10m UTP RJ12 cable, a built-in power cable and a 500A/50mV shunt.

Built-in bluetooth: with Victron Energy's free app, it can be monitored and configured via bluetooth from either a smartphone or tablet.

- Monitor battery voltage, charger amperage, current drawn by the load, current capacity of the battery in percentage and Ah
- Programmable relay: start generator, disconnect consumers
- The BMV-700 range is equipped with a 500A shunt, this can be optionally extended to a 10000A shunt
- Equipped with VE.Direct connector
- It stores the previously measured values, from which usage patterns can be established and the current battery status is known
- 5 year warranty, extendable to 10 years
